CQJ-3000 Auto Glue kitchen corrugated box glue machine
CQJ-3000 Auto Glue kitchen corrugated box glue machine
CCT adhesive machines bring together a no-carrier process, viscosity detection & control system, and a computer control program to be the most convenient way to boost the efficacy of corrugating lines. CCT has the latest and cleanest technologies coming together to create the most innovative products.
Quantity

Technical parameters
Specifications
Processing technologyboth carrier &.no-carrier
Gluecapability800-1600kgs/hour
One batch production time30-50min/tank
Tank material stainless steel or carbon steel (Customized)
General power32KW
Compressed airpressure0.5-0.8Mpa
Max air consumption0.68m3/min
Steam pressure 0.2-1.2Mpa
InstallationDimension 9500*3700*4000mm
Total weightabout4.5T
Machine introduction
Application:corrugated cardboard industry
Warranty:12 months free after installation acceptance
Place of Origin: Sichuan, China.
Packaging Material: plastic, plywood case, air bubble film packaging with moisture protection


Machineadvantages
  1. Fully automatic processing control
  2. Accurate feeding and stable quality
  3.  Improve Corrugator runnability, board quality, starch & energy usages
  4.  High solid content &. Low glue consumption
  1. Payment terms, delivery and after-sales service
® Payment:All the payment can negotiate, generally by T/T or L/C.
® Delivery:45-55 days after receipt of your downpayment
® Service:24 hours online support, 15days on-site installation &. Operation training
